Post Driver - PD-55 pneumatic medium duty c/w 3 7/8 inch (98.4 mm) master chuck

The legendary PD-55. For nearly forty years, the PD-55 and its predecessor the PD-50 have been the productivity leaders in post driving. At just 54 pounds, the brutally tough PD-55 is capable of handling your toughest applications quickly and efficiently. The PD-55 is ideally suited for driving t-posts, ground rod, tent stakes, grape stakes, delineator posts, form pins and fence posts up to 3 3/4”.

Specifications
Duty - Medium
Air Consumption (CFM@90 psi) - 42
Wt. lb (kg) - 54.6 (24.8)
Ship Wt. lb (kg) - 60 (27.2)
Master Chuck - 3-7/8” ID

Applications
3/4" to 1" Ground Rod
3/4" to 1-1/2" Reinforcing Bar Tent Stakes
1" Concrete Form Pins
1" Pipe
1-1/4" to 1-1/2" Pipe
1-5/8" Pipe
2" Pipe
2-1/2"
3" Pipe
T Posts
Telespar Posts
Telespar Post Breakaway Anchor 2-1/2"
Telespar Post Breakaway Anchor 3"
1.2 to 1.5 lbs/ft Channel Posts
2 to 2.75 lbs/ft Channel Posts
3 to 4 lbs/ft Channel Posts
Channel Post Breakaway Anchor
C Posts
Rectangular Posts
Fiberglass T Posts

Model and Part Number Specifications

PD-55 Medium Duty Post Driver with a 3 7/8" (98.4 mm) I.D. Master Chuck,
uses 42 CFM (1.19 m3/min) @ 90 psi (6.4 kg/cm2). Approx. Wt. 54.6 lbs (24.8 kg)

1 070609 3 1/2" (88.9 mm) I.D. Chuck Adapter

2 070610 3" (76.2 mm) I.D. Chuck Adapter

3 070611 2 1/2" (63.5 mm) I.D. Chuck Adapter

4 070612 2" (50.8 mm) I.D. Chuck Adapter

5 070613 1 1/2" (38.1 mm) I.D. Chuck Adapter

6 070614 1" (25.4 mm) I.D. Chuck Adapter

7 070617 Channel Post Chuck Adapter - 1.2 to 1.5 lbs/ft Posts

8 070618 Channel Post Chuck Adapter - 2 to 2.75 lbs/ft Posts

9 070619 Channel Post Chuck Adapter - 3 to 4 lbs/ft Posts
