12' 11-3/4" (4.0 m) or 16' 11-38" (5.2 m) height when forks reversed
Series 2412 Contractor Lift Dimensions
2412
Height max. (forks up)
12' 11-3/4"
4.0 m
Height max. (forks down)
12' 0"
3.7 m
Lift capacity
450.0 lb
200.0 kg
Height stowed
62.8"
159.4 cm
Length stowed
23.0"
58.4 cm
Length operating
48.0"
121.9 cm
Width stowed
26.4"
67.1 cm
Width operating
26.4"
67.1 cm
Winch cranks per foot
8
24/m
Basic weight
195 lb
88.5 kg
Series 2416 Contractor Lift Dimensions
2416
Height max. (forks up)
16' 11-3/8"
5.2 m
Height max. (forks down)
15' 11-5/8"
4.9 m
Lift capacity
450.0 lb
200.0 kg
Height stowed
62.8"
159.4 cm
Length stowed
23.0"
58.4 cm
Length operating
48.0"
121.9 cm
Width stowed
26.4"
67.1 cm
Width operating
55.25"
140.3 cm
Winch cranks per foot
8
24/m
Basic weight
243 lb
110.2 kg
Options:
Cable Stay Brake (# 784755)
Each mast and carriage can have a factory installed, gravity actuated safety brake which holds loads in place in the event the cable should go slack.
Fork Extension (#784695)
With the push of a button, forks may be extended from 23.3" (59.2cm) to 29.8" (75.7cm). When using the fork extensions the weight capacity reduces to 200 lb (90 kg), as is clearly marked on the extended forks. A second button returns the extension for storage inside forks.
Pipe Cradle (#783705)
Great for air ducts or other HVAC applications. Slides over forks. Packaged two per set
Tray (#784320)
24 x 28" (61 x 71 cm) steel tray slides onto forks.
